•  Double section welded frame structure;
  •  Easy operation and maintaining at the back;
  • 19” standard installation;
  • Removable side panels, side locks are optional, easy installing and maintaining;
  • Cable entry at the top cover and bottom panel;
  • 120mm fan optional
  • Turning angle of front door is above 180 degrees;
  • Turning angle of rear door is above 90 degrees.

  • Standard:
  • Comply with ANSI/EIA RS-310-D, DIN41494 part 1, IEC297-2,
  • DIN41494 part 7 standard
  • Loading capacity:  60KG

  • Material
  • SPCC cold rolled steel;
  •  Thickness:Mounting profile 1.5mm,others 1.2mm
  • Dimensions: 670 (W) x 670 (D) x 720 (H) mm

Understanding our 19” rack mount codes:

XXXXTME800

  • The first four digits refer to the height of the 19” rack. 1RU is the equivalent height of 1.75 inches (44.45mm).
  • When estimating the overall height, include extra height for the feet / coasters and foam protective materialwhen freighting the item

38RUXXX800

  • The next letters generally indicate the style of the door. TME is a vented metal door. TE is a glass door.

38RUTMEXXX

  • The final 3 digits indicate the cabinet depth. Generally you have 600mm or 800mm shelves.

(CABTZH6612BK)

12 Months
SKU CABTZH6612BK
Model # CABTZH6612BK
Brand BOURNE
Unit Of Measure Each
Assembled Width 32.000m
