24VDC 4A Single Output Industrial DIN Rail Power Supply

The PSDR24V4A is a 24VDC Class II DIN rail mount switching power supply, designed with a fully isolated plastic case to prevent user contact and the risk of shock. Features no load power consumption to save energy and protection against short circuit, over load, over voltage & over temperature.

Features

• 24VDC 4A Power output with universal 88~264VAC input
• Adjustable voltage range 24 ~ 25.5V; tailor voltage in longer cable runs
• Integrated protection against line overvoltage / overload / short circuit
• Integrate to protect IT & security in home, office and retail environments
• Designed for installation on DIN rail TS-35/7.5 or 15
• Prevents overheating with free air convection
• Double Insulated - Isolation Class II
• LED indicator for power on
• No load power consumption (<0.3W)

Specifications

• DC Voltage: 24V
• Rated Current: 4.2A
• Current Range: 0 ~ 4.2A
• Rated Power: 100.8W
• Ripple and Noise (max.): 150mVp-p
• Voltage Adj. Range: Pass LPS: 24 ~ 25.5V / Non LPS: 21.6 ~ 29V
• Voltage Tolerance: ±1.0%
• Line Regulation: ±1.0%
• Load Regulation: ±1.0%
• Setup, Rise Time: 500ms, 60ms/230VAC / 500ms, 60ms/115VAC at full load
• Hold Up Time: 50ms/230VAC / 18ms/115VAC at full load
• Voltage Range: 88 ~ 264VAC (277VAC operational) / 124 ~ 370VDC (390VDC operational)
• Frequency Range: 47 ~ 63Hz
• Efficiency: 90%
• AC Current: 3A/115VAC / 1.6A/230VAC
• In-rush Current: Cold Start - 35A/115VAC / Normal - 70A/230VAC
• Working Temperature:-30 ~ +70°C
• Working Humidity: 20 ~ 90% RH non-condensing
• Storage Temp., Humidity: -40 ~ +85°C , 10 ~ 95% RH
• Temp Coefficient: ±0.03%/0C (0 ~ 50°C)
• Vibration (Component): 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
• Vibration (Mounting): Compliance to IEC60068-2-6
• Dimensions: 70 x 90 x 54.5mm
