ENERGY SAVING - ES SERIES
Due to rising electricity costs, Energy Saving has becomeone of today's most important issues. It is a trend to operate ECO - Economical mode on big capacity on-line double conversion UPS. This seems to virtually turn UPS backto Stand by (0ff-line) era.
Upsonics new ES pure sine wave line-interactive UPS are based on Energy Saving technology. In addition to providing high quality Sine Wave power and low Harmonic Distortion to support both Linear and Non-linear loads theES series has a built in wide range AVR (automatic voltage regulator) on Bypass circuit which stabilises power and makes the ES series operate even more effectively and safely than an On-line double conversion UPS operated under ECO mode.
Features:
- 3yr RTB warranty / 2yr on batteries
- Pure sine wave Output on Battery
- Intelligent Charging controlled
- 98% Efficiency in ECO Mode
- Range 1.0KVA - 1.5KVA
- Intelligent interactive LCD control panel
- Multiple interfaces options: RS232/RS485/MODBUS/USB/SNMP
- Compact design
- Standard and long backup time
- Cold start - Starts on battery, no mains power required
- Protection against overload, overheating, surges, spikes, short circuit, over charging
- Ability to Integrate with Genset
- Easy battery replacement
- 5 IEC outlets
ES pure sine wave line-interactive UPS vs On-line double conversion UPS operated under ECO mode
- Wider input range: More than 10% wider input main power voltage range than an on-line UPS.
- High overall efficiency: Consumes much less power than an on-line double conversion UPS during bypass mode operation.
- Better stability: Concise designed compact unit gives better stability.
- Economically smaller: Smaller footprint. Less expense for users.
Possible Usage:
- Small to Enterprise Rackmount Servers
- Communication infrastructure
- Networking infrastructure
- Home Theatres incl Plasma / LCD
SPECIFICATIONS:
Line Interactive Sine wave output | 1RU UPS | Tower UPS | Rack / Tower Option for UPS | Long Run Time UPS require accompanying Battery Pack | Batt Pack | |||||||||||||
Model Energy Saver Series (ES xxx) | ES 1RU10 | ES 1RU15 | EST 10 | EST 15 | EST 20 | ESRT 10 | ESRT 15 | ESRT 20 | ESRT 30 | ESRT 50 | ESLR 10 | ESLR 15 | ESLR 20 | ESLR 30 | ESLR 50 | ESLR 75 | ES BP 3 RU | |
Capacity VA/Watt | 1.0/625 | 1.5/938 | 1.0/625 | 1.5/938 | 2.0/1250 | 1.0/625 | 1.5/938 | 2.0/1250 | 3.0/1875 | 5.0/3125 | 1.0/625 | 1.5/938 | 2.0/1250 | 3.0/1875 | 5.0/3125 | 7.5/4688 | ||
Input Nominal Voltage | 230 VAC | |||||||||||||||||
Voltage Range | 170 VAC ~ 300 VAC | |||||||||||||||||
Frequency | 45Hz - 70 Hz auto sensing | |||||||||||||||||
Boost Transfer | 208 VAC ± 2% | |||||||||||||||||
Boost Return | 218 VAC ± 2% | |||||||||||||||||
Buck Transfer | 252 VAC ± 2% | |||||||||||||||||
Buck Return | 242 VAC ± 2% | |||||||||||||||||
Low Voltage Transfer to Batt | 190 VAC ± 2% | |||||||||||||||||
Low Voltage Return | 200 VAC ± 2% | |||||||||||||||||
High Voltage Transfer to Batt | 286 VAC ± 2% | |||||||||||||||||
High Voltage Return | 276 VAC ± 2% | |||||||||||||||||
Output Wave Form | Pure Sine Wave | |||||||||||||||||
Efficiency | >80% | |||||||||||||||||
Overload Protection | Line Mode | >110% then buzzer alarm and amber LED continuously blinking | ||||||||||||||||
Battery Mode | 110% ~ 150% for 30 seconds: >150% for 200ms, then UPS Shuts Down | |||||||||||||||||
Short Circuit Protection | Line Mode | Circuit Breaker | ||||||||||||||||
Battery Mode | Electronic Circuit | |||||||||||||||||
Cold Start DC Start | Yes | |||||||||||||||||
Transfer Time | Typical <4ms | |||||||||||||||||
Battery Voltages | 24VDC | 24VDC | 24VDC | 36VDC | 36VDC | 24VDC | 36VDC | 36VDC | 36VDC | 48VDC | 24VDC | 36VDC | 48VDC | Various | ||||
Battery Amp | 6V 9Ah | 6V 9Ah | 7.2Ah | 7.2Ah | 9Ah | 7.2Ah | 7.2Ah | 9Ah | 7.2Ah | 9AH | Requires ES BP 3 RU Batt Box 7.2 OR 9 Ah as required | 16 x 7.2Ah or 9Ah | ||||||
LCD Display | UPS status; I/P & O/P Voltage, frequency; Load Level; Battery voltage & Level; internal temperaure Normal Green, Warning AmberFault RED |
|||||||||||||||||
Audible alarm | Battery Mode | Beeping every 4 seconds | ||||||||||||||||
Low Battery | Beeping every 1 second | |||||||||||||||||
UPS Fault | Continuous Beep | |||||||||||||||||
Overload | Beeping 2 x every second | |||||||||||||||||
Communications Interface | Various combinations of RS232; SNMP;USB; Dry Contact & AS 400 available as options | |||||||||||||||||
Dimensions (W/H/D in mm) |
440/44/515 | 440/44/515 | 145/210/380 | 145/210/445 | 145/210/445 | 440/88/465 | 440/132/465 | 440/132/620 | 440/88/465 | 440/132/465 | 440/132/465 | |||||||
Net Weight Kg | 18 | 20 | 16.5 | 17.5 | 22.5 | 16 | 17.5 | 24.5 | 36.9 | 49.8 | 16 | 17.5 | 24.5 | 25 | 34.6 | |||
Environment | Operating Environment | 0 - 40 Deg C Relative Humidity 0 - 95% Non Condensing | ||||||||||||||||
Noise Level | Less than 55dBA (@1.0 Meter) | |||||||||||||||||
Outlets / Connections | 4IEC | 4IEC | 3IEC | 6IEC | 10IEC | 10IEC + TB | 6IEC | 10IEC | 5IEC+Terminal Block |
(ESART30)
12 Months
SKU | ESART30 |
Model # | ESART 30-(ESART3000) |
Barcode # | 9345785003923 |
Brand | UPSONIC |
Unit Of Measure | Each |
Assembled Width | 35.100m |
