{tab Features}

Features:

  • The max output current 3A, long time use 2.1A, enoughuse.
  • Synchronous rectification, High efficiency,12V to 5V 1A can up to 92%.
  • Output 5V have 400W TVS tube protect your USB device.
  • Using the latest USB identification circuit, perfectly compatible with IPHONE, the most of Android phones, IPAD etc.
  • Output voltage indicator (Blue).
  • Input with reverse polarity protection diode, will not damage when input connect incorrect.
  • Provides complete fault protection such as input undervoltage lockout, output short circuit protection, over current protection and thermal shutdown.
  • Perfect for Equipment racks, Conference rooms, A V Systems, Planes, Yachts
{tab Specifications}

SPECIFICATIONS:

  • Main chip type: Non-isolated synchronous rectification
  • Input voltage: DC 6~24V
  • Output voltage: 5V
  • Output current: 3A Max
  • Conversion efficiency: 12V to 5V 1A can up to 92%
  • Switch frequency: 500KHz
  • Output ripple: 10mV around (12V to 5V @2A)
  • Static current: 0.85 mA
{/tabs}

(PK4918)

12 Months
SKU PK4918
Model # A-1407
Barcode # 9328202020697
Brand PRO2
Assembled Width 0.028m
