CAT6A cables support networking at gigabit speeds and are backwards compatible with CAT5E cables. Colour coded black for immediate and easy identification.

• -UTP Cable
• -24AWG(1/0.508BC)*4P(Conductor OD:0.90mm) & Cross
• -OD:6.2MM
• -Black 3C shining & white printing text
• -N121017 UTP CAT.6A NETWORK CABLE
• -ISO/IEC 11801

CABLE SPECIFICATIONS

•  Cable Type: Cat6A
•  Connectors: Un-terminated
•  Length: 350m
•  Colour: Black
•  Jacket Material: PVE
•  Insulation Material: HDPE
•  Diameter: Nominal 7.4mm

FEATURES

•  Unterminated
•  Bare Copper / 24AWG
•  Impedance Matched - Wire and connectors are carefully matched to virtually eliminate echoing and cancellation, providing high speed, error-free transmission
•  24AWG Bare Copper Conductors
•  Metre marked Black UV stabilised jacket

COMPLIANCES

•  All Proposed Category 5e requirements as per ANSI/TIA, ISO/IEC Standards
•  ANSI/TIA 568-C.2 CAT.6A and ISO/IEC 11801 CLASS E, 2nd Edition
•  RoHS compliant for the requirement of European Union issued Directive 2011/65/EU

APPLICATIONS

•  General Outdoor Application
•  1000BASE-T Gigabit Ethernet
•  10BASE-T, 100BASE-TX Fast Ethernet (IEEE 802.3)
•  100 VG - AnyLAN(IEEE802.12), 155/622 Mbps ATM
•  500MHz Broadband Video
•  Voice, T1, ISDN

WARRANTY

•  3-year limited warranty.
• PACKAGING DIMENSIONS
•  Weight:13KG
•  Dimensions: 33x33x30cm
