SCAN-SPEAK 4" FULL RANGE NEO DISCOVERY

10cm Fullrange 8 ohm, Small Neo Magnet, Coated Fiberglass Cone

NEODYMIUM MAGNET & COATED FIBREGLASS CONE

The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - it gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point.

  • Wide Frequency Range
  • Compact Neo magnet Motor
  • Copper Cap on Pole Piece
  • Vented Alu. Chassis, SBR Rubber Surround
  • High Sensitivity 86dB/2,83V
  • Coated NRSC Fibre Glass Cone (patent)



Description 10cm Fullrange 8 ohm, Small Neo Magnet, Coated Fiberglass Cone
Impedance 8Ω Re 6.8Ω
Power 10Wrms
Sens. 86.0dB
Fs 100Hz
Qes 0.65
Qms 2.44
Qts 0.51
Cms 0.86mm/N
Coil 19mmØ
Depth 40mm
Impedance (Ohm) 8 ohm
Inch 4
Le 0.11mH
Mag. 0.16kg
Mms 2.93g
Power (RMS) 0-50 Watt
Re 6.8Ω
Rms 0.76kg/s
Sd 36cm²
Size 4'
Type Full Range
Vas 1.57L
Width 98mm
Zn
Manufacturer Scan-speak
Price Type each
Series Discovery
Page 1

(10F-8414G10)

12 months

SKU 10F-8414G10
Model # 10F-8414G10
Brand SCANSPEAK
Unit Of Measure 1
