Network:

• Network Type:4G LTE
• Cellular Antenna:Internal
• APN:Auto APN details preloaded

GPS:

• GPS Antenna:Internal
• GPS Tracking:High Sensitivity with 72CH GLONASS
• GPS Amplifier:Low Noise GPS Signal Booster (LNA)

Smart Technology:

1-Accident & Rollover Detection:Configure accident and rollover alerts triggered by extreme changes in velocity and orientation of vehicle or equipment.Second-by-second GPS data is saved on the device’s flash memory,with a capacity of approximately 2 hours of data.In the event of an accident,a subset of the data (60 seconds before /10 seconds after) is uploaded to the server automatically (if configured) or can be requested manually for a detailed reconstruction of the incident.

2- Driver ID:Options RFID reader,iButton®,or Wiegand interface for Driver ID,access control,and logbooking.

3- Driver Safety & Behavior: Monitor speeding,harsh acceleration,braking,cornering,idling,and more to improve safety and prevent unnecessary wear on vehicles.

Geofence Alerts: The server can use device location to create geofences and alerts if an asset enters or leaves designated locations.

4  -Geofence Download to Device:Geofences can be downloaded directly to the device from Telematics Guru for enhanced location-based actions and alerts.2G - Maximum of 20 Geofences with up to 30 points per geofenceLTE-M/NB-IoT - Maximum of 500 Geofences with up to 100 points per geofence.

5 -Remote Immobilization Digital outputs can be connected to a relay to enable remote immobilization of vehicles and equipment in the case of theft, abuse,or unauthorized usage.

 6 GPS Jamming Detection:GPS Jamming or Interference can be detected and alerted on.

Real-Time Tracking: Device remains continuously connected while on the move for real-time asset tracking.

7 -Preventative Maintenance:Set reminders based on distance traveled and run hours to reduce maintenance and repair costs.

8-Lone Worker Safety:Interface a variety of duress pendants to enable man-down alerts for lone worker safety monitoring.

9- In-Vehicle Alerts: Can be wired up to external buzzers or lights for in-vehicle alerts.

10-Sensor Monitoring: Interface with a range of devices and switches for seatbelt detection,duress and panic buttons,lights,in-cab warning buzzers and more.

11-Theft Recovery:Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval.

12-Tamper Alerts: Instant alert if the device is disconnected from its power source

13- Run Hour Monitoring:Calculate run hours and distance traveled (odometer) to understand and optimize asset utilization

Backup:

• Flash Memory:Store weeks of records if device is out of cellular coverage.Storage capacity for over 10 days of continuous 30-second logging.

Power:

• Input Voltage:8-36V DC(max)
• High-Performance Automotive Power Supply:Stringent power load dump tests are conducted to ensure operation in the harshest automotive electrical systems.Built-in self-resetting fuse makes installation simple and safe.
• Operating Current: LTE-M / NB-Io -T:50mA when moving
• + ?60mA while internal battery charging
• Intelligent Power Management: Device enters sleep mode when vehicle is inactive                                 to prevent battery drain.
• Slee Current:<1mA
• Backup Battery:1100mAh LiPo internal backup battery pack.

General:

•  IP Rating:IP67 rated housing ensures device can withstand fine dust,high-pressure spray, submersion for 30 mins in 1m of water,and extreme temperatures.
• Housing:Ultra-Rugged IP67 Housing
• Dimensions:125 x 80 x 25 mm (4.92 x 3.15 x 0.98)
• Operating Temperature:-30°C to +60°C(connected to external power) At < 0°C and > +40°C the internal backup battery will not be charged as a safety precaution due to the dangers associated with charging batteries at extreme temperatures.
• Diagnostic LED:Diagnostic LED indicates operation status
• 3-Axis Accelerometer:3-Axis Accelerometer to detect movement,high G-force events,and more.
•  GPS Antenna:Internal
• Cellular Antenna:Internal
• On-Board Speed & Heading:The device continuously monitors speed and heading,allowing for over-speed alerts as well as updates on speed and heading changes.
• On-Board Temperature:The device reports internal temperature and prevents the internal battery charging in extreme temperatures.Internal temperature provides an indication of ambient temperature but may not always be precise.
• Installation:10 wire harness,1m Length .
