Features:

- Operating temperature: -20 to 100 degrees
- Bosses on internal base allow fixing of PCBs horizontally, or connection of terminals etc.
- The lid and base incorporate a tongue and groove sealing system with a EPDM gasket
- Lid fixing screws are M-4 stainless steel (non-magnetic) into threaded brass inserts
- Wall mounting holes and lid fixing screws are outside the sealing area thus preventing the ingress of moisture and dust

Specifications

Colour : Grey-Dark
IP Rating : IP65
Dust/Particle Ingress Protection : 6 - Dust tight, no ingress of dust
Liquid/Moisture Ingress Protection : 5 - Water jets
Width : 240.0mm
Height : 90.0mm
Depth : 160.0mm
Material : ABS Plastic (Acrylonitrile Butadiene Styrene)
PCB Internal Guide Slots : true
Internal Mounting Posts : true
Gasket sealing system : true
Lid Screws : 6.0pc
Ventilation Holes : false

(HB6134)

12 Months

SKU HB6134
Model # HB6134
Barcode # 9319236836989
Brand BOURNE
Artist / Author Amal
Shipping Weight 0.7000kg
Shipping Width 0.240m
Shipping Height 0.090m
Shipping Length 0.160m
Unit Of Measure Each
Assembled Length 0.160m
Assembled Height 0.090m
Assembled Width 0.240m
