HB6248

Features:
• Made with Polycarbonate material and moulded in light grey.
• Operating temperature : minus 40C to 125C
• The lid and base incorporate a toungue and groove sealing system with a EPDM gasket
• Lid fixing screws are M-4 stainless steel (non metallic) into threaded brass inserts
• Wall mounting holes and lid fixing screws are outside the sealing area thus preventing the ingress of moisture & dust
• Designed to IP65 of IEC 529and NEMA 4 (dust and hoseproof)
• Internal guide slots for mounting PCB assemblies vertically
• External mounting plate (4pcs) made of thermoplastic are available as an option
• External hinge kit (2pcs) made of thermoplastic are available as an option.



Specifications

Colour : Grey-Light
IP Rating : IP65
Dust/Particle Ingress Protection : 6 - Dust tight, no ingress of dust
Liquid/Moisture Ingress Protection : 5 - Water jets
Width : 171.0mm
Height : 55.0mm
Depth : 121.0mm
Material : Polycarbonate
PCB Internal Guide Slots : true
Lid Screws : 4.0pc






(HB6248)

12 Months
SKU HB6248
Model # HB6248
Barcode # 9319236868744
Brand BOURNE
Unit Of Measure Each
Assembled Length 0.121m
Assembled Height 0.055m
Assembled Width 0.171m
