The Hikvision HiLook IPC-B261H-MU 6MP Bullet Camera delivers exceptional image quality with its 6 MP resolution, ensuring clear and detailed footage in various lighting conditions. The camera’s 120 dB Wide Dynamic Range (WDR) technology guarantees effective imaging even in scenes with strong backlight, providing consistent clarity in all environments.

Features

  • 6 MP high-quality imaging
  • Efficient H.265+ video compression
  • 120 dB Wide Dynamic Range (WDR) for clear imaging in challenging lighting conditions
  • AI-based human and vehicle classification
  • Built-in microphone
  • IP67-rated
  • Power over Ethernet (PoE)
  • IR range of up to 40 metres for clear night vision with smart supplement light
  • Fixed 2.8 mm lens with a wide horizontal field of view of 107°
  • Supports multiple video compression formats including H.265, H.264, and MJPEG
  • Motion detection and video tampering alarm
  • Perimeter protection with line crossing detection and intrusion detection
  • Built-in microSD card slot supporting up to 256 GB of storage

AI-Powered Human and Vehicle Classification

  • Equipped with advanced deep learning algorithms, the IPC-B261H-MU excels in human and vehicle classification. This AI-powered feature helps improve surveillance accuracy by identifying and distinguishing targets, enabling more efficient monitoring and reducing false alerts.

Built-in Microphone for Enhanced Audio Security

  • The camera integrates a built-in microphone, offering real-time audio capabilities to complement video footage. This feature allows for complete situational awareness, making it a valuable addition for environments where both visual and auditory surveillance are necessary.

Weatherproof and Durable Design

  • Designed for demanding environments, the IPC-B261H-MU features an IP67 rating, making it both water and dust resistant. Its rugged construction ensures reliability in outdoor settings, regardless of weather conditions, making it suitable for both residential and commercial applications.

Efficient Bandwidth and Storage Management

  • The IPC-B261H-MU utilises H.265+ compression technology to significantly reduce bandwidth and storage requirements without compromising video quality. This efficient compression ensures long-term storage without overwhelming network infrastructure, making it an ideal choice for large-scale surveillance setups.

Easy Installation with PoE Support

  • The camera supports Power over Ethernet (PoE), simplifying installation by reducing the need for separate power cables. This feature streamlines the setup process and provides flexible placement options, making the camera perfect for a wide range of security systems.

Flexible Viewing Angles and Adjustable Lens

  • The IPC-B261H-MU offers versatile mounting options with its adjustable pan, tilt, and rotation angles. With a 2.8 mm fixed lens providing a wide field of view (107° horizontal, 57° vertical), it ensures comprehensive coverage of the monitored area. Additionally, the camera's lens is designed for optimal image clarity with an F1.6 aperture for enhanced low-light performance.

Category

Specification

Details

Model Version

IPC-B261H-MU

6 MP Fixed Bullet Network Camera

Camera

Image Sensor

1/2.8" Progressive Scan CMOS



Min. Illumination

Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR



Shutter Speed

1/3 s to 1/100,000 s



Wide Dynamic Range

120 dB



Day & Night

IR cut filter



Angle Adjustment

Pan: 0° to 360°
Tilt: 0° to 90°
Rotate: 0° to 360°

Lens

Lens Type

Fixed focal lens



Focal Length & FOV

2.8 mm
horizontal FOV 107°
vertical FOV 57°
diagonal FOV 128°



Aperture

F1.6

Illuminator

IR Wavelength

850 nm



IR Range

Up to 40 m

Video

Max. Resolution

3200 × 1800



Main Stream

50 Hz: 20 fps (3200 × 1800)
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)



Sub-Stream

50 Hz: 25 fps (1280 × 720, 960 × 540, 640 × 480, 640 × 360)



Third Stream

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)



Compression

H.265/H.264/H.264+/H.265+

Audio

Audio Compression

G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC



Audio Bit Rate

64 Kbps (G.711ulaw/G.711alaw)
16 Kbps (G.722.1)
16 Kbps (G.726)
16 Kbps to 64 Kbps (AAC)
32 to 192 Kbps (MP2L2)
8 to 320 Kbps (MP3)



Audio Sampling Rate

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz



Environment Noise Filtering

Yes

Network

Protocols

TCP/IP, ICMP, HTTP
HTTPS, FTP, DHCP
DNS, DDNS, RTP
RTSP, NTP, UPnP
SMTP, IGMP, 802.1X
QoS, IPv4, IPv6
UDP, Bonjour, SSL/TLS
PPPoE, SNMP



Simultaneous Live View

Up to 6 channels



Security

Password protection
complicated password
HTTPS encryption
IP address filter
Security Audit Log
TLS 1.1/1.2

Interface

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port



On-Board Storage

MicroSD card slot
supports up to 256 GB

General

Camera Material

Aluminium alloy body
IR cover: plastic



Camera Dimensions

Ø 70 mm × 161.7 mm



Package Dimensions

216 mm × 121 mm × 118 mm



Camera Weight

Approx. 485 g



Power Consumption

12 VDC
0.5 A, max. 6 W
PoE (802.3af) max. 7.2 W



Power Supply

12 VDC ± 25%
PoE: 802.3af, Class 3

Approval

EMC

FCC, CE-EMC, RCM, IC, KC



Safety

UL, CB, CE-LVD, BIS



Environment

CE-RoHS
WEEE
Reach



Protection

IP67 (IEC 60529-2013)



(SEC-HL-00006)

SKU SEC-HL-00006
Model # IPC-B261H-MU
Barcode # 6931847138080
Brand HikVision HiLook
