Specification
Industry Standard Compatible with EIA-RS310D standard 19" cabinets
M/B Form Factor ATX (12" x 9.6"), CEB (12" x 10.5")
Drive Bay • External: 5.25" x 3, 3.5" x 1
• Internal: 3.5" x 3, or 3.5" x 2 & 2.5" x 1
Power Supply Supports:
• PS2 single PSU
• 550W/800W/1200W/1600W 1+1 CRPS 80 Plus Platinum
Indicators Power status, HDD, LAN activity LEDs
Front Control Panel Power switch, system reset, USB 2.0 x 2
Chassis Security Intrusion switch (optional)
Cooling Fans • 120 x 25mm PWM front fan x 1, 3500RPM
• 80 x 25mm PWM rear fan x 2 (optional), 4200RPM
• 80 x 25mm PWM rear fan x 2 (optional), 4500RPM
Expansion Slot Full height PCIe slots x 8
Material • Material: SGCC
• Thickness: 1.2mm
Rail Kit Supports 28" tool-less & ball-bearing slide rails
Product Dimensions (DxWxH; Chassis Only) 515x 430 x 174.8mm
(20.3" x 16.9" x 6.9")

Package Dimensions (DxWxH) 696 x 610 x 310mm
Weight (Chassis Only) • Net weight: 11.5kg
• Gross weight: 14.7kg
Cubic Feet 4.65



(R400N)

SKU R400N
Model # R400N
Brand Inwin
