Features

• 24-inch 2MP (1920 × 1200) IPS Display
• 600cd/m² Brightness (Typ.)
• Internal Front Calibration Sensor
• Focus View Mode / Pathology Mode
• Daisy Chain
• Bi-directional Auto Pivot

Specifications

Display

• Size [Inch]: 24
• Aspect Ratio: 16:10
• Surface Treatment: Anti-Glare
• Response Time: 5ms (GtG at Faster)
• Resolution: 1920 — 1200
• Pixel Pitch [mm]: 0.27 — 0.27
• Viewing Angle (CR10): 178° (R/L), 178° (U/D)
• Brightness (Typ.) [cd/m²]: 600
• Contrast Ratio (Typ.): 1000:1
• Colour Gamut (Typ.): NTSC 70% (CIE1931)
• Colour Bit: 8bit

Connectivity

• 12G-SDI: NO
• 3G-SDI: NO
• D-Sub: NO
• DVI-D: YES (1ea)
• Component (Resolution): NO
• Composite (Resolution): NO
• HDMI: YES (1ea)
• Daisy Chain: YES
• DisplayPort: YES (In 1ea / Out 1ea)
• Thunderbolt: NO
• Headphone Out: NO
• RS-232: NO
• S-Video: NO
• USB Downstream Port: YES (2ea / ver3.0)
• USB Upstream Port: YES (2ea / ver3.0)

Features

• HDR 10: NO
• Auto Luminance Sensor: YES
• Smart Energy Saving: YES
• PIP: NO
• PBP: NO
• Flicker Safe: YES
• HW Calibration: YES
• Black Stabiliser: YES
• Lighting: NO
• Reader Mode: YES
• Super Resolution+: YES
• Hot Key: NO
• Presence Sensor: NO
• Front Sensor: YES
• Colour Temperature: 6500K / 7500K / 9300K / Manual (5000K–10000K)
• Rotation & Mirror Mode: NO
• Failover Input Switch: NO
• Focus View: YES
• Light Box Mode: NO
• Brightness Stabilisation: YES
• Pathology Mode: YES
• DICOM Compliant: YES
• HDR Effect: NO

Mechanical

• Display Position Adjustments: Tilt / Height / Swivel / Pivot
• Borderless Design: Normal
• Wall Mountable [mm]: 100 — 100
• OneClick Stand: YES
• Mechanical Power Switch: NO

Dimensions / Weights

• Dimension in Shipping (W — H — D): 705 — 480 — 200 mm
• Dimension with Stand (W — H — D): 574.2 — 559.4 — 248.2 mm
• Dimension without Stand (W — H — D): 574.2 — 382.4 — 59.3 mm
• Weight in Shipping: 9.7 kg
• Weight with Stand: 7.1 kg
• Weight without Stand: 4.35 kg

Power

• Power Consumption (Max.): 65W
• Power Consumption (DC Off): Less than 0.3W
• AC Input: 100–240V (50/60Hz)
• Type: External Power (Adapter)
• DC Output: 19V, 3.42A

Accessory

• Adapter: YES
• Calibration Report (Paper): YES
• Display Port: YES
• DVI-D: YES
• DVI-D (Colour/Length): YES
• D-Sub: NO
• HDMI: YES
• HDMI (Colour/Length): YES
• Power Cord: YES
• USB3.0 Upstream Cable: YES

SW Application

• Dual Controller: YES
• LG Calibration Studio (True Colour Pro): NO
• Qubyx: NO

Standard

• UL (cUL): YES
• CE: YES
• RoHS: YES
• IP (Front/Except for front): NO
• Vandal-proof: NO
• KGMP: YES
• KC (for Rep. of Korea): YES
• IEC (IEC 60601-1 / IEC 60601-1-2): YES
• EN (EN 60601-1 / EN 60601-1-2): YES
• IEC (IEC 60950-1 / IEC 55032, 55024): YES
• EN (EN 60950-1 / EN 55032, 55024): YES
• FDA: Class II
• ISO13485: YES
• GMP: YES
• WEEE: YES
• MFDS: YES
• REACH: YES
