MQS75 2-WAY STEREO CONVERTER

The MQS75 is designed to be connected between mics and the mixer. Each mic channel on the MQS75 has both phantom power and low-frequency cut selectable via DIP switches plusa level control. The balanced XLR line output can be connected to a mic input on the mixer and headphones or a powered monitorcan be connected to the Phone/Aux output. If AC power is notavailable, the MQS75 runs on batteries as well as with an ACadaptor (optional).

Specifications
Max Output Level:
Balance: +18dB
Unbalance: +12dB
Max Input Level:
Balance: +22dB
Unbalance: +22dB
Input Impedance: RCA 100KU/XLR 10KU
Output Impedance: RCA 100U/XLR 100U balance
Noise Floor: -88dB
Gain:
+4dB In: -8Db
-10dB In: +20dB
THD: 0.003%
Power: 12V DC/ 150mA adapter
Dimension: 143x 93x 45 mm
Weight: 527g

(MQS75)

12 month warranty

SKU MQS75
Model # MQS-75
Barcode # 9328202033642
Brand McLELLAND
Unit Of Measure each
Assembled Width 0.717m
