POE Splitter 100Mt Range 5VDC/ 12VDC Output

TL-POE10R PoE Receiver Adapter - TP-LINK

The PoE Receiver Adapter TL-POE10R fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Supplier Adapter, such as TP-LINK’s TL-SF1008P or TL-POE150S, or other equivalent product, to deliver 12V or 5V Direct Current to where there are no power line or outlet, where you wish to fix a non-POE compliant device such as AP, IP Camera or IP Phone, etc.

IEEE 802.3af compliant
Delivers power over 100 meters
Can switch between 12V DC or 5V DC power supply output
Plug-and-Play, requires no configuration

Standards and Protocols		IEEE 802.3, 802.3u, 802.3af CSMA/CD, TCP/IP
Basic Function		Compatible with IEEE 802.3af compliant PSEs
		Delivers power up to 100 meters
		Optional 12VDC or 5VDC power supply
		Plug-and-Play
Ports	LAN Port	1 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
	PoE Port	1 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
Network Media		10BASE-T: UTP category 3, 4, 5 cable (maximum100m) EIA/TIA-568 100¦¸ STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100¦¸ STP (maximum 100m)
LED Indicator		PWR
Safety & Emission		FCC, CE
Dimensions (WDH)		3.22.00.9 in.(815224 mm)
Environment		Operating Temperature: 0¡æ~40¡æ (32¨H~104¨H) Storage Temperature: -40¡æ~70¡æ (-40¨H~158¨H) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Power Output		12W (12VDC) or 11.5W (5VDC)
