Ruijie Reyee ES209MG-P 8-Port 2.5G PoE+ 1 x SFP+ Port Cloud Managed Switch 130 W
SKU: WIF-RY-00320
High-performance 2.5G PoE switch for advanced multi-device connectivity
The RG-ES209MG-P is a next-generation 8-port 2.5G Cloud-Managed PoE switch with a 10 Gbps SFP+ uplink designed for fast, stable, and intelligent networking. Engineered for professional installations, it combines high PoE power, fanless reliability, and Ruijie’s lifetime cloud management—delivering smooth integration for offices, surveillance, and smart systems.
Key Features
- Enhanced multi-gigabit performance: Eight 2.5 GbE ports and one 10 Gbps SFP+ uplink deliver superior bandwidth for high-demand applications.
- Powerful PoE capability: Eight IEEE 802.3af/at-compliant ports provide up to 130 W total PoE power, ideal for powering IP cameras, access points, and IoT devices.
- Quiet, fanless operation: Natural cooling in a metal enclosure ensures silent, reliable performance for indoor deployments.
- Smart cloud management: Full support for Ruijie Cloud and Reyee App allows remote configuration, monitoring, and firmware upgrades anytime, anywhere.
- Energy-efficient operation: Consumes only 8.5 W (no load) and 138.5 W at full PoE load, maintaining high efficiency and low power loss.
- Robust design and protection: 200,000 hours MTBF, surge protection ±4 kV, and ESD protection (air 8 kV, contact 6 kV) ensure long-term reliability.
With its combination of high throughput, strong PoE capacity, and smart management, this switch is the ideal backbone for high-density, multi-device networks.
| Technical Specifications | |
|---|---|
| Product Category | Layer 2 |
| RJ45 Ports | 8 × 10/100/1000/2500BASE-T |
| Optical Ports | 1 × 10GE SFP+ |
| PoE Out Ports | 8 × IEEE 802.3af/at |
| PoE Budget | 130 W |
| Switching Capacity | 60 Gbps |
| Forwarding Rate | 45 Mpps |
| Power Input | 100–240 V AC, 50–60 Hz |
| Power Output | 54 V DC / 2.78 A |
| Max Power Consumption | 138.5 W (PoE full load) |
| Memory | Flash 4 MB |
| VLAN Support | Up to 16 VLANs (IEEE 802.1Q) |
| MAC Address Table | 4,000 entries |
| Jumbo Frame Size | 9,216 bytes |
| Fan | Fanless, natural cooling |
| Mounting Options | Wall / Desk mount |
| Dimensions (W × D × H) | 202 × 108 × 28 mm |
| Weight | 0.66 kg (net), 1.63 kg (shipping) |
| Operating Temperature | 0 °C to 40 °C |
| Storage Temperature | –40 °C to 70 °C |
| Humidity Range | 10–90 % RH (non-condensing) |
| Surge Protection | ±4 kV (common and differential mode) |
| ESD Protection | Air 8 kV / Contact 6 kV |
| Certification | CE, EN 55032, EN 55035, EN 62638-1 |
| Warranty | 3 Years |
| General Information | |
|---|---|
| Manufacturer: | Ruijie Reyee |
| Manufacturer Part Number: | RG-ES209MG-P |
| Barcode: | 90012788 |
| Packaging Details | |
| Weight: | 1.39 KGS |
| Width: | 10.00 (cm) |
| Height: | 3.00 (cm) |
| Depth: | 18.00 (cm) |
(WIF-RY-00320)
| SKU | WIF-RY-00320 |
| Model # | RG-ES209MG-P |
| Barcode # | 90012788 |
| Brand | Ruijie Reyee |
