The Ruijie Reyee RG-NBR6120-E High-performance Cloud Managed Security Router is designed to cater to the needs of businesses with up to 200 users and boasts a maximum throughput of 600 Mbps. This advanced networking solution combines cutting-edge technology with seamless cloud management, ensuring optimal performance, scalability, and security. The RG-NBR6120-E is engineered to deliver high-speed connectivity, making it an ideal choice for businesses that require rapid data transfer and uninterrupted access to online resources. With its impressive maximum throughput of 600 Mbps, this router guarantees efficient data transmission and minimizes network congestion, enabling smooth operation even during peak hours. What sets this router apart is its cloud-managed functionality, providing businesses with the convenience of centralized management and configuration. Through an intuitive and user-friendly cloud management platform, administrators can effortlessly monitor and control the router's settings from anywhere, eliminating the need for on-site configuration and reducing management complexity. This cloud-based approach allows for easy scalability and ensures that businesses can adapt to changing network demands seamlessly.
the Ruijie Reyee RG-NBR6120-E High-performance Cloud Managed Security Router is a top-tier networking solution tailored for businesses seeking exceptional performance, scalability, and security. With its impressive maximum throughput, cloud-managed functionality, robust security features, and support for up to 200 users, this router is an invaluable asset for organizations aiming to enhance their network infrastructure and drive business growth.
FEATURES:
- High-performance Cloud Managed Security Router designed for businesses with up to 200 users
- Boasts a maximum throughput of 600 Mbps for rapid data transfer and uninterrupted access
- Cloud-managed functionality allows for centralized management and configuration from anywhere
- An intuitive and user-friendly cloud management platform eliminates the need for on-site configuration
- Scalable design to adapt to changing network demands seamlessly
- Robust security features including advanced firewall, VPN support, IDPS, and content filtering
- Supports QoS controls, VLAN support, and advanced routing protocols for optimized network performance
- Sleek and compact design for easy integration into any office environment
- Durable construction and high-quality components ensure long-lasting reliability
- Enhances network infrastructure and drives business growth in a competitive digital landscape
RG-NBR6000 Series Specifications
| Specification | RG-NBR6120-E | RG-NBR6205-E | RG-NBR6210-E | RG-NBR6215-E |
|---|---|---|---|---|
| WAN Port | 1 x 10/100/1000 Base-T port | 1 x 10/100/1000 Base-T port | 1 x 10/100/1000 Base-T port | 1 x 10/100/1000 Base-T port |
| LAN Port | 1 x 10/100/1000 Base-T port | 1 x 10/100/1000 Base-T port | 1 x 10/100/1000 Base-T port | 1 x 10/100/1000 Base-T port |
| LAN/WAN Switchable Port | 3 x 10/100/1000 Base-T ports | 6 x 10/100/1000 Base-T ports, 2 x 1GBase-X SFP ports | 6 x 10/100/1000 Base-T ports, 2 x 1GBase-X SFP ports | 6 x 10/100/1000 Base-T ports, 1 x 1GBase-X SFP port, 1 x 10GBase-X SFP+ port |
| Throughput | 600 Mbps | 1.5 Gbps | 2.5 Gbps | 2.5 Gbps |
| Client (Recommended) | 200 | 500 | 1000 | 2000 |
| CPU | 2 Cores, 880 MHz | 2 Cores, 1.2 GHz | 3 Cores, 1.2 GHz | 4 Cores, 1.2 GHz |
| SDRAM/RAM | 512 MB | 2 GB | 2 GB | 2 GB |
| Flash Memory | 4 GB EMMC | 8 GB EMMC + 8 MB SPIFLASH | 8 GB EMMC + 8 MB SPIFLASH | 8 GB EMMC + 8 MB SPIFLASH |
| Hard Disk Drive | Not Supported | 1 TB (Not delivered with the router, can be added) | 1 TB (Not delivered with the router, can be added) | 1 TB (Not delivered with the router, can be added) |
| LED | 1 x System Status LED, 1 x Power Status LED | 1 x System Status LED, 1 x Power Status LED, 1 x SATA LED | 1 x System Status LED, 1 x Power Status LED, 1 x SATA LED | 1 x System Status LED, 1 x Power Status LED, 1 x SATA LED |
| Button | 1 x Power button | 1 x Power button | 1 x Power button | 1 x Power button |
| Dimensions (W x D x H) | 440 mm x 43.6 mm x 200 mm (17.32 in. x 1.72 in. x 7.87 in., without rubber pads) | 440 mm x 43.6 mm x 200 mm (17.32 in. x 1.72 in. x 7.87 in., without rubber pads) | 440 mm x 43.6 mm x 200 mm (17.32 in. x 1.72 in. x 7.87 in., without rubber pads) | 440 mm x 43.6 mm x 200 mm (17.32 in. x 1.72 in. x 7.87 in., without rubber pads) |
| Mounting Method | Rack-mounted | Rack-mounted | Rack-mounted | Rack-mounted |
| Rack Size | 1U 19-inch Rack-mounted | 1U 19-inch Rack-mounted | 1U 19-inch Rack-mounted | 1U 19-inch Rack-mounted |
| Fan | N/A | 2 | 2 | 2 |
| Operating Temperature | –5ºC to 45ºC (23°F to 113°F) | 0ºC to 45ºC (32°F to 113°F) | 0ºC to 45ºC (32°F to 113°F) | 0ºC to 45ºC (32°F to 113°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) | 10% to 90% RH (non-condensing) | 10% to 90% RH (non-condensing) | 10% to 90% RH (non-condensing) |
| PPPoE Server Accounts | 200 | 500 | 1000 | 2000 |
| Internet Access Mode | PPPoE Client, DHCP Client, Static IP | PPPoE Client, DHCP Client, Static IP | PPPoE Client, DHCP Client, Static IP | PPPoE Client, DHCP Client, Static IP |
| Access Mode Auto-Identification | Yes | Yes | Yes | Yes |
| WAN Address Collision Avoidance | Yes | Yes | Yes | Yes |
| VLAN | Yes | Yes | Yes | Yes |
| IPv6 | Yes | Yes | Yes | Yes |
| SNMP | Yes | Yes | Yes | Yes |
| Port Isolation | Yes | Yes | Yes | Yes |
| Port Mirroring | Yes | Yes | Yes | Yes |
| LAN Port Link Aggregation | No | Yes | Yes | Yes |
| App Block (Time/IP-based Policy) | Yes | Yes | Yes | Yes |
| Website Filtering (Blacklist/Whitelist) | Yes | Yes | Yes | Yes |
| Application Identification | Yes | Yes | Yes | Yes |
| Application Priority | Yes | Yes | Yes | Yes |
| User Flow Control Policies | Yes | Yes | Yes | Yes |
| IP-based Automatic Bandwidth Assignment | Yes | Yes | Yes | Yes |
| VPN Flow Control | Yes | Yes | Yes | Yes |
| System Log | Yes | Yes | Yes | Yes |
| Log Storage | Yes | Yes | Yes | Yes |
| Fault Diagnosis | Yes | Yes | Yes | Yes |
| Authentication | Portal Authentication, Password Authentication, Voucher Authentication, SMS Authentication | Portal Authentication, Password Authentication, Voucher Authentication, SMS Authentication | Portal Authentication, Password Authentication, Voucher Authentication, SMS Authentication | Portal Authentication, Password Authentication, Voucher Authentication, SMS Authentication |
| L2TP VPN | Yes | Yes | Yes | Yes |
| PPTP VPN | Yes | Yes | Yes | Yes |
| IPsec VPN | Yes | Yes | Yes | Yes |
| L2TP/PPTP Tunnels | 16 | 400 | 600 | 1000 |
| L2TP/IPsec VPN Performance | 8 Mbps | 400 Mbps | 600 Mbps | 1000 Mbps |
| Static Routing | Yes | Yes | Yes | Yes |
| RIP/RIPng | Yes | Yes | Yes | Yes |
| OSPFv2 | Yes | Yes | Yes | Yes |
| OSPFv3 | No | Yes | Yes | Yes |
| Equal-Cost Multi-Path Routing | Yes | Yes | Yes | Yes |
| Policy-Based Routing | Yes | Yes | Yes | Yes |
| Active/Standby Switchover of Ports | Yes | Yes | Yes | Yes |
| WAN Load Balancing | Yes | Yes | Yes | Yes |
| PPPoE Client | Yes | Yes | Yes | Yes |
| PPPoE Server | Support (CLI) | Support (CLI) | Support (CLI) | Support (CLI) |
| DHCP Server | Yes | Yes | Yes | Yes |
| DHCP Snooping | Yes | Yes | Yes | Yes |
| DNS Client | Yes | Yes | Yes | Yes |
| DNS Server | Yes | Yes | Yes | Yes |
| DNS Proxy | Yes | Yes | Yes | Yes |
| FTP Client | Yes | Yes | Yes | Yes |
| FTP Server | Yes | Yes | Yes | Yes |
| TFTP Client | Yes | Yes | Yes | Yes |
| NTP Client | No | Yes | Yes | Yes |
| DDNS | Cloud DNS | Cloud DNS | Cloud DNS | Cloud DNS |
| NAT | Yes | Yes | Yes | Yes |
| ACL | Yes | Yes | Yes | Yes |
| Time-based Extended ACL | Yes | Yes | Yes | Yes |
| SYN Flood Attack Guard | No | Yes | Yes | Yes |
| UDP Flood Attack Guard | No | Yes | Yes | Yes |
| ICMP Flood Attack Guard | No | Yes | Yes | Yes |
| ICMP Redirection Attack Guard | No | Yes | Yes | Yes |
| ICMP Unreachable Packet Attack Guard | No | Yes | Yes | Yes |
| Fraggle Attack Guard | No | Yes | Yes | Yes |
| Overlength ICMP Packet Attack Prevention | No | Yes | Yes | Yes |
| Winnuke Attack Guard | No | Yes | Yes | Yes |
| IP-based Security Domain Division | No | Yes | Yes | Yes |
| Security Domain Division based on Physical Port (Sub Interface and Aggregation Port) and Dialup Port | No | Yes | Yes | Yes |
| Cloud Management | Yes | Yes | Yes | Yes |
| App Management | Yes | Yes | Yes | Yes |
| App Upgrade | Yes | Yes | Yes | Yes |
| App Restart | Yes | Yes | Yes | Yes |
| Router | 1 | 1 | 1 | 1 |
| Power Cord | 1 | 1 | 1 | 1 |
| Power Cord Retention Clip | 1 | 1 | 1 | 1 |
| Rubber Pads | 4 | 4 | 4 | 4 |
| Mounting Brackets | 2 | 2 | 2 | 2 |
| M4 x 8 mm Screws | 6 | 6 | 6 | 6 |
| DB-9 Console Cable | 1 | 1 | 1 | 1 |
| Ethernet Cable | 1 | 1 | 1 | 1 |
| User Manual | 1 | 1 | 1 | 1 |
| Warranty Card | 1 | 1 | 1 | 1 |
| Package Weight | 14.66 kg | 17.08 kg | 17.08 kg | 17.08 kg |
| Package Dimension (w x d x h) | 560 mm x 470 mm x 380 mm | 560 mm x 470 mm x 380 mm | 560 mm x 470 mm x 380 mm | 560 mm x 470 mm x 380 mm |
| General Information | |
|---|---|
| Manufacturer: | Ruijie Reyee |
| Manufacturer Part Number: | RG-NBR6120-E |
| Barcode: | 6971693273658 |
| Packaging Details | |
| Weight: | 2.38 KGS |
| Width: | 5.00 (cm) |
| Height: | 20.00 (cm) |
| Depth: | 44.00 (cm) |
(WIF-RY-00221)
| SKU | WIF-RY-00221 |
| Model # | RG-NBR6120-E |
| Barcode # | 6971693273658 |
| Brand | Ruijie Reyee |
