Share a 3G/4G* mobile connection, compatible with 120+ LTE/HSPA+/HSPA/UMTS/EVDO 3G/4G USB modems, tested in the field

Travel-size Design, small and light enough to take on the road, enables users to share a 3G/4G* mobile connection wherever 3G/4G* coverage is available

Wireless speed is up to 150Mbps

Three modes available for different situations: 3G/4G* Router, WISP Client Router and Travel Router Mode (APMode)

With 3G/4G* and WAN failover back-up strategy, TL-MR3020 can provide a sustained internet connection.

Travel-sized Design

With the travel-sized and compact design, TL-MR3020 is small enough to take on the road and make sure that you can share a 3G internet connection wherever wireless 3G coverageis available.

Travel Router with 3G/4G Function

TL-MR3020 is the ideal travel partner for people on the go. 3G Router Mode enables you to plug in a 3G USB modem andshare it wirelessly. Its Travel Router Mode (AP Mode) allowsyou to conveniently setup an internet connection utilizing ahotel WAN cable. Meanwhile, you can also use the switch on the side of the router to choose between Travel Router Mode,3G Router Mode and WISP Client Router Mode based on your different requirements.

Power Supply

TL-MR3020 provides you a mini USB port to be connected toyour laptop or power adapter for power supply.

Specifications

HARDWARE FEATURES
Interface	1 10/100Mbps WAN/LAN Port, USB 2.0 Port for 3G/4G modem, a mini USB Port for power supply.
Button	Reset Button, Mode Switch
External Power Supply	5VDC/1.0A
Dimensions ( W x D x H )	2.9 x 2.6 x 0.9 in. (74 x 67 x22 mm)
Antenna Type	Internal Antenna
Compatibility	NBN - Fibre to the Premises (FTTP) - WAN Preferred or WAN Only Modes.
	NBN - Fibre to the Home (FTTH) - WAN Preferred or WAN Only Modes.

	WIRELESS FEATURES
Wireless Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency	2.4-2.4835GHz
Transmit Power	<20dBm
Wireless Modes	3G Router, Travel Router (AP), WISP Client Router
Wireless Security	Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, Wireless MAC Filtering
SOFTWARE FEATURES
Security	Firewall, MAC filtering, Denial of Service (DoS)
DHCP	Server, DHCP Client List, Address Reservation
Port Forwarding	Virtual Server, Port Triggering, DMZ, UPnP
Access Control	Parental Control, Host List, Access Schedule, Rule Management
OTHERS
Certification	CE, FCC, RoHS
Package Contents	TL-MR3020 router, QIG, Power Adapter, USB Cable, Resource CD, Ethernet Cable
System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, 10, MAC® OS, NetWare®, UNIX® or Linux.
Environment	Operating temperature:-10°C~60°C
	Storage Temperature: -40°C~80°C
	Operating Humidity: 10%~90% non-condensing
	Storage Humidity: 5%~90% non-condensing
