CAT5E OUTDOOR TOUGHCABLE 305M

{tab Overview}

Ubiquiti Outdoor Shielded CAT5e Ethernet Cable - TOUGHCable Pro

The industrial-grade, Category 5e TOUGHCable™ protects your networks from the most brutal environments.

TOUGHCable^™ PRO

A Category 5e, outdoor, carrier-class shielded cable features an integrated ESD drain wire.

Increased Performance

TOUGHCable^™ dramatically increases your Ethernet link states, speeds and overall performance.

Extreme Weatherproof Design

TOUGHCable^™ has been builtto perform in even the harshest weather and environments.

ESD Damage Protection

TOUGHCable^™ protects your networks from devastating electrostatic discharge attacks.

Extended Cable Support

TOUGHCable^™ has been developed to increase power handling performance for extended cable run lengths.

TOUGHCable^™ Connectors

Specifically designed for use with TOUGHCable^™, the TOUGHCable Connectors protect against ESD attacks and Ethernet hardware damage, while allowing rapid field deployment without soldering.

Additional Details

• 24 AWG copper conductor pairs
• 26 AWG integrated ESD drain wire to prevent ESD attacks and damage
• PE outdoor-rated, weatherproof jacket
• Multi-layered shielding
• Available in lengths of 1000 ft (304.8 m)

{tab Specifications}

Specifications: TOUGHCable^™ PRO

Cable	CAT5e, Shielded
Ethernet Support	Up to 1 Gbps
Conductor Wire Gauge	24 AWG
Conductor	Solid Bare Copper
Conductor Diameter	0.500 ± 0.005 mm
Insulation Type	Solid PE
Insulation Thickness	Avg. 0.26 mm, Min. 0.25 mm
Insulation Diameter	1.04 ± 0.03 mm
Separation (Polyester Wrapping)	Thick: 0.025 mm, Extent: 20 mm
Anti-Crosstalk Divider	None
Cable Shield (Aluminum Foil)	Thick: 0.060 mm, Extent: 18 mm
ESD Drain Wire	0.4 CCS
Rip Cord	Yes
Jacket Material	PE
Jacket Thickness	Avg. 0.50 mm, Min. 0.46 mm
Jacket Outer Diameter	6.0 ± 0.30 mm
Jacket Color	Black
Reference Standard	ISO/IEC 11801, TIA/EIA568B.2
Installation Temperature	-20 to 60° C
Storage Temperature	-30 to 75° C
Operation Temperature	-40 to 80° C
