Hybrid Couplers are used to develop advanced RF transmission systems where interaction-free signal combining is required. 4×4 matrices are typically used as an in-building multi-network combiner. High-performance 700-3800MHz 4x4 port hybrid coupler with N-female connectors. Ideal for signal distribution. Durable and reliable.

Powertec’s 4×4 Hybrid Matrix is a highly effective repeater combiner which is commonly used to distribute multiple 4G/5G services across multiple distribution feeder cables. The four input ports allow up to four repeaters to be combined across four outputs with a -6 dB coupling loss. Providing more effective division than Power Dividers, 4×4 Hybrid Couplers are used extensively even with installations with only two or three repeaters.

FEATURES:

• Covers 4G/5G frequencies from 700 to 3800 MHz
• 6 dB Coupling across four outputs (25:25:25:25%)
• Low PIM -153 dBc
• 4x N Female input and 4x N Female output ports
