The next generation of power storage is here! These LiFePO4 batteries weigh less than half of their Lead Acid counterparts. They may look fairly similar to lead acid batteries, but internally they’re a totally different, next generation concept. They’re actually made up of regular prismatit LiFePO4 cells, which are in mass production for many portable devices. An internal battery management system (BMS) ensures all cells are uniformly charged and discharged, as well as providing short circuit, over current, and reverse polarity protection. This provides you with a higher degree of protection than a traditional lead acid battery which is unprotected, and can discharge rapidly under short circuit conditions, causing fire and damage. The internal BMS will also limit discharge and manage cut-off voltage, to further protect the internal cells.

This 100Ah model can provide continuous current up to 50A, with peaks of up to 100A. It’s not suitable for a primary vehicle starting battery, however is absolutely perfect for house batteries, backup batteries, and virtually any other application where you would typically use a large lead acid / AGM battery.

Features:

  • Much lighter than Lead Acid and AGM Batteries
  • Robust LiFePO4 Cells
  • Excellent life span

Specifications:

Width : 325mm
Height : 220mm
Depth : 170mm
Battery usage : Bulk Storage
DC Voltage : 12.8V
DG UN Number : 3480
DG Ship Name : 3480 - Lithium Ion Batteries
DG Pack Group : II - Medium Danger
DG Hazardous Chemical Code : 4W
Amp Hour Rating : 100Ah
Packaged Height : 25cm
Packaged Length : 38cm
Packaged Width : 20cm
Packaged Weight : 11kg
Type of battery : li-ion
DG Class : 9
Packaged Volume : 19l
Peak Discharge Duration : 5sec
Battery Watt Hour Rating (Required for Lithium Batteries) : 1Wh
Battery Peak Current : 150A
20 Hour Capacity : 100Ah
Connection Type : M8 Bolt/Nut
Operating Temperature : 45°C, 0°C
Recharging Voltage : 14.6V, 14.6V
Charging Method : Constant CurrentConstant Voltage
Weight : 11kg
Standard Recharge Current : 40A
Storage Temperature : 0°C, 40°C
Operating Humidity : 85%, 0%
Storage Humidity : 0%, 50%
Internal Resistance : 60mΩ
Nominal Voltage : 12.8V
Cut-Off Voltage : 9.2V
Battery Chemical Composition : Lithium Ferrous Phosphate (LiFePO4)
Continuous Current : 100A



(SB2215)

SKU SB2215
Barcode # 9319236758052
