Gigabyte AMD Radeon™ RX 7700 XT GAMING OC 12G, 18 Gbps, GDDR6, 192 bit, PCI-E 4.0, 8 Pin*2, DisplayPort 2.1 *2 HDMI 2.1 *2

KEY FEATURE

• Powered by Radeon™ RX 7700 XT
• Integrated with 12GB GDDR6 192-bit memory interface
• WINDFORCE Cooling System
• RGB Fusion
• Dual BIOS
• Protection metal back plate

WINDFORCE COOLING SYSTEM

• The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 7 composite copper heat pipes, a large copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.

WINDFORCE COOLING SYSTEM

• The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 7 composite copper heat pipes, a large copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.

ALTERNATE SPINNING

• Reduce the turbulence of adjacent fans and increase airflow pressure.

3D ACTIVE FAN

• The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.

UNIQUE BLADE FAN

• The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.

GRAPHENE NANO LUBRICANT

• Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.

SCREEN COOLING

• Extended heatsink allows air to pass through, providing better heat dissipation.

SPECIFICATION

• Graphics Processing: Radeon™ RX 7700 XT
• Stream Processors: 3456
• Memory Clock: 18 Gbps
• Memory Size: 12 GB
• Memory Type: GDDR6
• Memory Bus: 192 bit
• Card Bus: PCI-E 4.0
• Digital max resolution: 7680x4320
• Multi-view: 4
• Card size: L=302 W=130 H=56 mm
• PCB Form: ATX
• DirectX: 12 Ultimate
• OpenGL: 4.6
• Recommended PSU:700W
• Power Connectors: 8 Pin*2

Output:

• DisplayPort 2.1 *2
• HDMI 2.1 *2

Core Clock

• Boost Clock : up to 2599 MHz (Reference card: 2544 MHz)
• Game Clock : up to 2276 MHz (Reference card: 2171 MHz)
