Note: The HR08 requires a 5V USB power source to function (not supplied).

Features

  • Bandwidth upto 48Gbps,Resolution upto 8K@60HZ YUV 4:4:4
  • Transmit upto 10m under 8K@60Hz 4:4:4; 25m under 4K 60Hz
  • 1x HDMI In, 1xHDMI Out, 1x Micro USB
  • This HDMI 2.1 compliant device supports CEC HDR10, HDCP, DSC, and 7.1ch audio
  • An inclused USB Type-A power cable is provided to connect to an available USB port or USB wall charger

Specifications

Operating Temperature Range

-5 to +35°C(+23 to +95°F)

Operating Humidity Range

5 to 90%RH (No Condensation)

Input DDC Signal

5 volts p-p(TTL)

Data transfer speed rate

48Gbps(Maximum)

Video Format Supported

DTV/HDTV:
480i/576i/480P/576P/720P/1080i/1080P/
8K@60Hz/4K@120HZ
4K2K@60/50/30/24Hz
3D video support

Video Output

HDMI

Support Video Color Format

xv-YCC/deep color 36bit

Support Audio Format

DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD

Power consumption

1watts(Maximum)

Dimension (L×W×H)

57x37.9x18mm

Net Weight

0.01kg

(HR08)

SKU HR08
Model # HR08
Barcode # 9328202036438
Brand Pro2
