Category Specification Details
Model Version RG-NBS5300-8MG2XS-UP 8-Port L3 Managed Switch with 2.5 Gbps and 10 Gbps SFP+
Layer Type Layer 3 Managed Switch
Switching Capacity Total Capacity 480 Gbps
Forwarding Rate Rate 360 Mpps
MAC Address Table Table Size 32,000 entries
VLANs Maximum VLANs 4094
Ports PoE++ 8 x 2.5 G RJ45 PoE Ports, 90W per Port
PoE Power Budget Total Budget 370W
Uplink Ports 10 Gbps SFP+ 2 x 10G SFP+ Uplink Ports
Fan Cooling 1 Fan
Port Surge Surge Protection 6 kV
Dimensions W x D x H 442 mm x 313 mm x 175 mm
Weight Net Weight 9.6 kg (with package)
MTBF Mean Time Between Failures > 400,000 hours
Certification Compliance CE
Management Cloud Management Lifetime management on Ruijie Cloud
Security Features Security IP-MAC-Port Binding
ACL
Port Security
Storm Control
DHCP Snooping
802.1X
Radius Authentication
General Information
Manufacturer: Ruijie Networks
Manufacturer Part Number: RG-NBS5300-8MG2XS-UP
Barcode: 6971693279636
Packaging Details
Weight: 3.25 KGS
Width: 23.00 (cm)
Height: 5.00 (cm)
Depth: 30.00 (cm)



(WIF-RY-00264)

SKU WIF-RY-00264
Model # RG-NBS5300-8MG2XS-UP
Barcode # 6971693279636
Brand Ruijie Networks
