Ubiquiti UniFi U6+, Dual-band WiFi 6 PoE Access Point

AP 2x2 Mimo, 2.4GHz @ 573.5Mbps & 5GHz @ 2.4Gbps,300+ Devices *No POE Injector

Experience the future of wireless connectivity with the Ubiquiti U6+, the Plus UniFi Compact AP that brings the power of Wi-Fi 6 to your network. With a compact design measuring Ø160mm × 33mm, this cutting-edge access point delivers exceptional performance and efficiency without compromising on space. The U6+ is designed to meet the demands of modern, data-intensive applications, making it an ideal choice for homes, businesses, or educational institutions.

The U6+ takes advantage of Wi-Fi 6 (802.11ax) technology, providing faster speeds, increased capacity, and improved performance in high-density environments. Enjoy seamless connectivity on both 2.4GHz and 5GHz bands, ensuring optimal performance for a wide range of devices. With advanced features like MU-MIMO and BSS Coloring, the U6+ maximizes network efficiency, delivering a superior wireless experience for all users.

For added convenience, please note that the PoE injector is not included with the U6+. This ensures flexibility in power supply options, allowing you to tailor your network setup to specific requirements. Elevate your wireless network to the next level with the Ubiquiti U6+, embracing the latest in Wi-Fi technology within a sleek and compact form factor. Unleash the potential of Wi-Fi 6 for improved speeds, increased capacity, and enhanced performance in a variety of environments.


Features

  • Wi-Fi 6 Powerhouse: Ubiquiti U6+ is a cutting-edge Wi-Fi 6 (802.11ax) access point, ensuring faster speeds, increased capacity, and superior performance for data-intensive applications.
  • Compact Design: U6+ with dimensions of Ø160mm × 33mm is a UniFi Compact AP, delivering exceptional wireless connectivity without compromising space—ideal for homes, businesses, or educational institutions.
  • Dual-Band Connectivity: Seamless 2.4GHz and 5GHz connectivity caters to diverse devices, ensuring optimal performance in high-density environments.
  • Advanced Features: U6+ incorporates features like MU-MIMO and BSS Coloring, maximising network efficiency for a superior wireless experience.
  • Flexible Power Options: Note that the PoE injector is not included, offering flexibility in power supply options for tailored network setups.
  • Future-Ready Technology: Elevate your network with U6+, embracing the latest Wi-Fi 6 tech for improved speeds, increased capacity, and enhanced performance across diverse environments.

Specifications

Speifications

Mechanical
Dimensions Ø160mm × 33mm (Ø6.3″ × 1.3″)
Weight Without Mount: 338g (0.8lb)
With mount: 413g (0.9lb)
Enclosure Material Polycarbonate, aluminum
Mount Material ABS, SGCC steel
Hardware
Networking Interface (1) GbE RJ45 port
Management Interface Ethernet
Power Method PoE
Supported Voltage Range 44–57V DC
Max. Power Consumption 9W
Max. TX Power
2.4 GHz
5 GHz
6 GHz

23 dBm
23 dBm
MIMO
2.4 GHz
5 GHz
6 GHz

2 × 2 (DL/UL MU-MIMO)
2 × 2 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz
6 GHz

573.5 Mbps (BW40)
2.4 Gbps (BW160)
Antenna gain
2.4 GHz
5 GHz
6 GHz

3 dBi
5.4 dBi
LEDs White/blue
Button Factory reset
Mounting Wall, ceiling (Included)
Ambient operating temperature -30°C to 60°C (−22°F to 140°F)
Ambient Operating Humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
Wi-Fi Standards 802.11a/b/g/n/ac/ax (Wi-Fi 6)
Wireless Security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest Traffic Isolation Supported
Zero-wait DFS Yes*
*Supported with upcoming firmware versions.
Concurrent Clients 300+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (Wi-Fi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
Software
Management Application UniFi Network: Version 7.3.76 and later

(U6-PLUS)

SKU U6-PLUS
Model # U6-PLUS
Barcode # 810084691090
